Linear 2GIG-PANIC1-345 User Manual

2 Copyright © 2014 Linear LLC
IMPORTANT: Alwa ysdisposeand/orrecycleusedbatteries in
accordancewiththehazardouswasterecoveryandrecycling
regulationsforyourlocation.Yourcity,state,orcountrymay
alsorequireyoutocomplywithadditionalhandling,recycling,
anddisposalrequirements.
3 Insertthereplacementbatterywiththepositive(+)signfacingup.
4 Ifyouremovethecircuitboard(notrecommended),ensurethe
LEDalignswiththeappropriateholeonthetopcover.
5 Verifythatthepanicbuttonisprogrammedintothecontrolpanel
andensurethat ithasqualityradiofrequency(RF)communications
withthepanel.
NOTE: TolearnhowtoprogramawirelesssensorintotheControl
Panel,seetheControlPanel’ sInstallation&Programming
Guide.
6 Replacethepanicbutton’stopcover.
WARNING: Failuretofollowthesewarningsandinstructionscan
leadtoheatgeneration,rupture,leakage,explosion,fire,or
otherinjury,ordamage.Donotinsertthebatteryintothe
compartmentinthewrongdirection.Alwaysreplacethe
batterywiththesameorequivalenttype(seeSpecifications).
Neverre
chargeordisassemblethebattery.Neverplacethe
batteryinfireorwater.Alwayskeepbatteriesawayfromsmall
children.Ifbatteriesareswallowed,promptlyseeadoctor.
WARNING: Afterreplacingthebattery,alwaystestthepanic
button.Fortestinginformation,seetheControlPanel’ s
Installation&ProgrammingGuide.
Activating the Panic Button Remote
Toactivatethepanicbutton:
1 Pressandholdthepanicbuttonforapproximatelytwo (2)seconds.
WhentheLEDil
luminatesRED,asignalistransmittedtothe
controlpanel.
2 WhenthecontrolpanelalarmsoundsandtheSysteminAlarm
messagedisplays,enteryourcodetosilencethealarm.Anyvalid
usercodewillsilencethealarm.
Analarmrep
ortistransmittedtothemonitoringservice.To
acknowledgethatthealarmreportwassent,tapOK.
3 Ifyouwanttoclearthealarmhistoryonthecontrolpanel,tap
ClearAlarmHistory.Thisplacesacheckmarkinthecorresponding
box.ThentapOK.
SPECIFICATIONS
WirelessSignalRange 500ft(152.4m),openair,withWirelessAlarm
ControlPanel
CodeOutputs Alarm;Supervisory;LowBattery
TransmitterFrequency 345.00MHz(crystalcontrolled)
UniqueIDCodes Overone(1)milliondifferentcodecombinations
SupervisoryInterval 70minutes
LED REDwhenactivated
Dimensions(LxWxH) 1.65x1.20x0.50in.(4.19x3.05x1.27cm)
Weight(includingbatteryand
bracket)
0.45oz.(12.8g)
HousingMaterial ABSPlastic
Color WhitewithGreyButton
Operatingtemperature 32°to120°F(0°to49°C)
RelativeHumidity Water‐Resistant
Battery(included,notinstalled) One(1)PanasonicCR2032orequivalentLithium
battery
RegulatoryListings Anatel,ETL,FCC,IC,IFETEL,andNOM
REGULATORY INFORMATION
FCC Notice
ThisdevicecomplieswithPart15oftheFCC'sRules.Operationis
subjecttothefollowingtwoconditions:
1 Thisdevicemaynotcauseharmfulinterference,and
2 Thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
Thisequipm
enthasbeentest edandfound tocomplywiththelimits
foraClassBdigitaldevice,pursuanttoPart15oftheFCCRules.These
limitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.
Thisequipmentgenerates,usesandcanradiateradiofrequency
energyand,ifnoti
nstalledandusedinaccordancewiththe
instructions,maycauseharmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurina
particularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbedetermined
byturningtheequip
mentoffandon,theuserisencourag edtotryto
correcttheinterferencebyoneormoreofthefollowingmeasures:
• Reorientorre
locatethereceivingantenna.
•Increasethese
parationbetweentheequipmentandreceiver.
• Connecttheequipmen
tintoanoutletonacircuitdifferent
fromthattowhichthereceiverisconnected.
•Consultthedealeroranex
periencedradio/TVtechnicianfor
help.
Thispr
oductcomplieswithFCCradiationexposurelimitsforan
uncontrolledenvironment.Avoidoperatingthisproductatadistance
lessthan20cmfromtheuser.
CAUTION: Anychangedormodificationsnotexpresslyapproved
bythepartyresponsibleforcompliancecouldvoidtheuser's
authoritytooperatethisequipment.
