Page #6 background image
4
FACTORY DEFAULTS
MASTER PROGRAMMING CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123456
ENTRY CODE LENGTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 DIGITS
REQUEST-TO-EXIT OUTPUT RELAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MAIN RELAY
ALARM SHUNT OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DISABLED
FORCED ENTRY OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OUTPUT #3
DOOR AJAR OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OUTPUT #4
MAIN RELAY ON TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 SECONDS
AUXILIARY RELAY ON TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 SECONDS
SOLID STATE OUTPUT #3 ON TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 SECONDS
SOLID STATE OUTPUT #4 ON TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 SECONDS
DOWNLIGHT ON TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 MINUTES
DOOR SENSE/INHIBIT INPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DOOR SENSE
KEYPAD LOCKOUT OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DISABLED
KEYPAD ACTIVE OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DISABLED
BEEPER SOUNDS WHEN KEY PRESSED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . YES
BEEPER SOUNDS DURING RELAY #1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NO
BEEPER SOUNDS DURING RELAY #2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NO
BEEPER SOUNDS DURING OUTPUT #3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NO
BEEPER SOUNDS DURING OUTPUT #4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NO
KEYPAD LOCKOUT COUNT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 TRIES BEFORE LOCKOUT
ANTI-PASSBACK TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NO ANTI-PASSBACK
AUTO-RELOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
BASIC PROGRAMMING
When the AK-21 is in Programming Mode, both indicators will turn
off until programming begins. After a programming option number
is entered the yellow indicator will blink. This shows that the AK-21
is ready to accept the new programming data. After the new data
entry is complete, the yellow indicator will fl ash while the data is
being stored. The green indicator will light if the data is accepted.
The red indicator will light if any programming data is entered
incorrectly, and the command will have to be fully re-entered.
Entering Programming Mode
The 6-digit Master Programming Code (default = 123456) is used to enter
Programming Mode.
Press: # 9 # Master Code
Master Code = the current 6-digit Master Programming Code
Exiting Programming Mode
Press: * * #
The red indicator will light after exiting Programming Mode.
NOTE: The AK-21 will automatically exit Programming Mode after two
minutes of inactivity.
Re-entering a Command After a Mistake
If the red indicator lights, signaling an incorrect entry, or an incorrect key is
pressed during programming, to clear the keypad and re-enter the command:
Press: * 9 #
Setting Entry Code Length Default: 4 digits
Press: 0 3 # Length #
Length = 1 - 6 for entry code length
NOTE: If the Entry Code Length is going to be changed from the factory
default of four digits, make this change fi rst, before programming any
entry codes.
Adding a New Entry Code
Press: 01 # Code # Code # Action #
Code = The new entry code: 1-999999, depending on code length
Action = Relay output entry code will activate as follows:
1 = Relay #1, timed open
2 = Relay #2, timed open
3 = Both Relays, timed open
10 = Relay #1, toggled
20 = Relay #2, toggled
30 = Both Relays, toggled
12 = Relay #1 toggled; Relay #2, timed open
21 = Relay #1 timed open; Relay #2 toggled
The yellow LED will fl ash quickly while the AK-21 searches its
memory for available space and duplicate entries. The green LED
will light when the new code is stored.
If the new entry code chosen is already being used for another
entry code, the red LED will light. A new unique code needs to be
entered.
NOTE: Leading zeros (zeros before the code number, i.e. 0001) do not need
to be entered when programming a new entry code. The AK-21 will internally
add any zeros to fi ll all digits determined by the entry code length setting.
Leading zeros will have to be entered by the user when entering their code
to gain access.
Erasing a Single Entry Code
Press: 0 2 # Code # Code #
Code = The entry code to delete.
The yellow indicator will fl ash quickly while the AK-21 searches its
memory for the code to erase. The green indicator will light when
the code is erased.
Erasing All Entry Codes
WARNING: PERFORMING THIS COMMAND WILL
REMOVE ALL ENTRY CODES FROM THE MEMORY.
Press: 9 7 # 0 0 0 0 0 0 # 0 0 0 0 0 0 #
NOTE: The green indicator will light while the memory is being erased. This
may take up to 15 seconds.
Changing the 6-Digit Master Programming Code
Press: 9 8 # Master Code # Master Code #
Master Code = The new 6-digit Master Programming Code
New master code: _____________________
228045 A IMAGE 6
Question and Answer IconNeed help?

Do you have a question about the Linear ACCESS AK-21 and is the answer not in the manual?

Linear ACCESS AK-21 Specifications

Power IconPower
voltage12-24 Volts AC or DC
current typical30 mA
current maximum150 mA
Outputs IconOutputs
main relay current5 Amps @ 28 Volts maximum
auxiliary relay current1 Amp @ 28 Volts maximum
solid state outputs current100 mA @ 24 VDC maximum
Operating Environment IconOperating Environment
temperature range-22°F to 149°F (-30°C to 65°C)
humidity range5% to 95% non-condensing
Weight and Dimensions IconWeight and Dimensions
width3.00 inches
height5.00 inches
depth3.00 inches

Summary

Keypad Features

Form "C" Relay Contacts

Main Relay (5A) and Auxiliary Relay (1A) for switching.

Input Functions

Door Sense, Inhibit, and Request-to-Exit inputs supported.

Wiring Diagram

Terminal Block Connections

Details for AK-21 terminals TB1 and TB2.

Wiring Notes and Cautions

Important instructions and safety warnings for wiring.

Installation

Opening the Keypad

Steps to disassemble the keypad for installation.

Keypad Wiring

Door Strike Wiring

Connecting the electric door strike to the keypad.

Power Supply Wiring

Connecting the power source to the keypad terminals.

Sense Input Wiring

Wiring for door sense or inhibit functions.

Request-to-Exit Input Wiring

Connecting a pushbutton for codeless access.

Factory Defaults

Basic Programming

Entering Programming Mode

Procedure to enter programming mode with master code.

Programming Tasks

Adding Entry Codes

Steps to add new entry codes and assign relay actions.

Erasing Entry Codes

Procedures for deleting single or all entry codes.

Changing Master Code

Procedure to update the 6-digit master programming code.

Programming Options

Door Sense or Inhibit Input

Configure input terminal #8 for door sense or inhibit.

Keypad Lockout and Anti-Passback

Resetting the Keypad

Master Reset Procedure

Clears all settings and entry codes to factory defaults.

Resetting the Master Code

Procedure to reset the master code to the default (123456).
