CHAPTER 2 MAINTENANCE LH50DU SERVICE MANUAL 19.1
CHAPTER 2 MAINTENANCE PAGE. 2-
LUBRICATION RECOMMENDATIONS
NOTE:
1.More often under severe use, such as wet or dusty conditions.
2.Grease: Light weight lithium-soap grease.
3.Grease M：Molybdenum disulfide (MoS
2
) grease (water resistant).
4.When suspension action becomes stiff or after washing.
5.Hours are based on 10 mph(16Km/h) average.
2.2 THROTTLE PEDAL INSPECTION
THROTTLE FREEPLAY
If the throttle pedal has excessive play due to cable
stretch or cable misadjustment, it will cause a delay
in throttle speed. Also, the throttle may not open fully.
If the throttle pedal has no play, the throttle may be
hard to control, and the idle speed may be erratic.
Check the throttle pedal play periodically in
accordance with the Periodic Maintenance Chart
and adjust the play if necessary.
THROTTLE FREEPLAY INSPECTION
1. Apply the parking brake.
2. Put the gear shift lever in the N(Neutral) position.
3. Start the engine, and warm it up thoroughly.
4. Measure the distance the throttle pedal moves
before the engine begins to pick up speed. Free
play should be 1.5 – 3 mm.
Adjustment
1. Slide the boot off inline cable adjuster sleeve.
Loosen adjuster locknut.
2. Turn adjuster until 1.5 to 3 mm, freeplay is
achieved pedal. NOTE: While adjusting freeplay,
it is important you flip the throttle lever back and
forth.
3. Tighten locknut.
