CHAPTER 3 CHASSIS LH50DU SERVICE MANUAL19.1
CHAPTER 3 CHASSIS PAGE. 3-
11. Insert new A-arm bushings and new A-arm shaft into new A-arm.
12. Install new A-arm assembly onto vehicle frame. Apply Loctite™ 242 to screw threads of the
A arm bolts and torque bolts to 44 ft. lbs. (60 Nm ).
DO NOT reuse old bolts. Serious injury or death could result if fasteners come loose during
operation.
13. Attach A-arm to rear knuckle. Tighten upper and lower bolts to 44 ft. lbs. (60 Nm ).
14. Install the shock and tighten shock bolt to 32 ft.lbs. (44 Nm).
15. Install the stabilizer and tighten nut to 40 ft.lbs. (56 Nm).
16. Re-install wheel and caliper.
Upon A-arm installation completion, test vehicle at low speeds before putting into regular
service.
