CHAPTER 3 CHASSIS LH50DU SERVICE MANUAL19.1
CHAPTER 3 CHASSIS PAGE. 3-
3.3 REAR STABILIZER BAR REMOVAL/INSTALLATION
1. Elevate and safely support vehicle with weight
removed from the rear wheel(s).
2. Remove the rear wheel to gain access to the
stabilizer bar, each side.
3. Remove the stabilizer bar nut from the lower
A-arm, each side.
4. Remove the two bolts that secure the stabilizer
bar to the main frame, each side.
To Next Page
