CHAPTER 3 CHASSIS LH50DU SERVICE MANUAL19.1
CHAPTER 3 CHASSIS PAGE. 3-
5. Remove the stabilizer from the fram.
6. Inspect the stabilizer bar. Inspect the bushings
and replace if needed.
7. Inspect the stabilizer joint and replace if needed.
8. Reverse the procedure for installation.Torque the
stabilizer bolts to 23 ft.lbs (32 Nm).
3.4 FRONT STRUT REPLACEMENT
1. Hold strut rod with wrench and remove top nut.
2. Compress spring.
3. Remove upper strut pivot assembly.
