CHAPTER 6 ELECTRICAL LH50DUSERVICE MANUAL19.1
CHAPTER 6 ELECTRICAL CTRICAL PAGE6
6.2 Check whether the three-phase wiring between motor and controller is reliable.
Poor contact can cause damage to the controller.
Motor Encoder
7ćMotor check
Connections with the controller are normal, and when you tap the accelerator, you find that
the car doesn't move, or it jitters at a very slow speed. The motor encoder is normal,
but the motor phase sequence is not correct. It needs to change the U V or V W phases of the
motor . Or motor encoder abnormality, such as encoder power supply abnormality,
disconnection, poor terminal contact, terminal sequence error, encoder damage.
