CHAPTER 6 ELECTRICAL LH50DUSERVICE MANUAL19.1
CHAPTER 6 ELECTRICAL CTRICAL PAGE6
16
replace the “ DC-DC Voltage Converter”。
Refer to " DC-DC Voltage Converter INSPECTION"
6. Wiring connection (entire lighting system)
Check the connection of the entire lighting system POOR CONNECTIONS
correct
6.6 LCD Meter
1. Engine working hour counter
and The odometer
7. Turn indicator light (L)
8. Turn indicator light(R)
2. Voltmeter
9. Reverse indicator light
3. gear position Indication
10. High beam indicator light
4. Mode indication
11. Speedometer
5. Ammeter
6.Neutral indicator light
A: km/ mile selector
B: hour / distance selector
6.7 MAIN SWITCH
12. Overheat warning lamp
13. Coulomb meter
14. Motor rpm meter
