CHAPTER 3 ENGINE M750L SERVICE MANUAL 18.0
CHAPTER 3 ENGINE PAGE 3-
74
3.17.3THERMOSTAT
Order
Job name/ Part name
Q'ty
Remarks
Thermostat removal
Drain the coolant
Remove the parts in order.
Refer to "COOLANT REPLACEMENT"
section.
1
Outlet hose , Cylinder head
1
2
Minor cycle conduit
1
3
Inlet hose , radiator
1
4
Thermostatic holder
1
5
Thermostatic cover
1
6
Thermostatic valve
1
7
Thermostatic shell
1
Reverse the removal procedure for
installation.
INSTALLATION
1. Inspect:
⚫Thermostatic valve
Valve does not open at 63-67℃→Replace.
Inspection steps:
⚫Suspend the thermostatic valve in a vessel.
⚫Place a reliable thermometer in water.
⚫ Observe the thermometer, while continually
stirring the water.
