LK-CP64X Control Panel (6A)
05 06
¢ Remote control
— The controller encodes by 433MHz learning code, can store 10 sets of transmission codes
— The controller defaults to mulple channel, single channel controler has the same way as
mulple channel one
.
£ Matching code
— Power the controller on, choose the channel(s) you want to set, can be set to any
combinaon of channel 1-4
— Pressing STOP buon on controller for 5 seconds
— LED flashes 3 mes and turns off
— Choose the channel you want to set on the remote
— Press UP within 15 seconds
— LED flashes 3 mes and turns off
— Code matched successfully
.
£ Clearing single code
— Power the controller on
— Keep pressing STOP key on the controller for 5S
— LED flashes 3 mes and turns off
— Press DOWN buon on the remote within 15 seconds
— LED flashes 3 mes and turns off
— Code cleared successfully
.
£ Clearing all codes
— Power controller on
— Pressing STOP /DOWN buon on the controller for 5 seconds
— LEDs flash 3 mes and turn off
— All the codes will be deleted aer this operaon
¢ Signal control
.
.
£ Reset and shielding
— Manual signal. Control the window by the buons on itself, external dry contact manual
switch and RF remote
— Cascaded signal. As a master controller sends signal to the slave controller, can also be
used as slave controller to receive the signal from the master controller to drive the
window
— Fire signal. Capable of receiving a signal from fire center, smoke sensor, gas detector open
the window automacally, send feedback signal to fire centre
— Rain signal. Aer receiving the signal of rain sensor close the window
— Temperature/humidity signal. Control the window by processing external
temperature/humidity sensor
— Aer manual signal processed controller receives input signal in real me
— Aer processing the signal from fire centre, smoke sensor or gas detector, the controller
immediately shields all the input signals, the controller must be reset by pressing K1
manually
— Aer wired rain sensor signal processed, the controller shields lower priority signal, only
receives the higher priority signal unl reset or manual signal processed
— Aer T&H sensor signal processed, the controller is in the reset state
— If the controller is not connected to a temperature and humidity sensor, the T/H port
must be shielded (put opon switch to “Y” posion)
£ Signal and priority
Priority
Signal
Device
1
Manual signal
Panel buons, manual switch, remote, master controller
2
Fire signal
Smoke sensor, gas detector
3
W/R signal
Wired wind rain sensor
4
T/H signal
Temperature sensor, humidity sensor
