Linksys BEFSR41 Quick Installation Guide

7
6 Heart Beat Signal
Heart Beat Signal is a service used in
Australia only. If you are using a Heart
Beat Signal connection, check with
your ISP for the necessary setup
information. When you are finished,
go to Step E.
7 L2TP
Use L2TP as a service only if
requested by your ISP. Check with
your ISP for the necessary setup
information. When you are finished,
go to Step E.
E Depending on the setup
information from your ISP, you
may need to provide a host
name and domain name for
the Router. The Host Name and
Domain Name fields are
usually left blank. If requested
by your ISP (usually cable ISPs),
complete these two fields.
F If you haven’t already done so,
click the Save Settings button.
Then close the web browser.
G Power your cable or DSL
modem off and back on
again.
H Restart or power on your PCs so
they can obtain the Router’s
new settings.
D6
D7

Linksys BEFSR41 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Supports ISDN connection	No
Web-based management	-
Ethernet LAN (RJ-45) ports	4
Certification	FCC, CE
Minimum system requirements	TCP/IP\\r Internet Explorer 5.0 / Netscape 6\\r CD-ROM
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black, Blue

Weight and Dimensions

Depth	48 mm
Width	186 mm
Height	154 mm
Weight	320 g
