Linksys E2100L Appendix C: Specifications
56
Advanced Wireless-N Router
Appendix C: Specifications
Model Name Linksys E2100L
Description Advanced Wireless-N Router
Model Number E2100L
Standards 802.3, 802.3u, 802.11b, 802.11g,
802.11n
Ports Internet, Ethernet [1-4], USB, Power
Buttons Wi-Fi Protected Setup, Reset
LEDs LAN [1-4], Wi-Fi Protected Setup™,
Wireless, Internet, Power
Cabling Type CAT 5e
# of Antennas 2
Connector Type R-SMA
Detachable (y/n) Yes
RF Pwr (EIRP) in dBm 802.11n: HT20: Typ. 17 +/-1.5 dBm
@ Normal Temp Range (2 Chains)
HT40: Typ.: 15 +/-1.5 dBm @
Normal Temp Range (2 Chains)
802.11g: Typ.: 15 +/- 1.5 dBm @
Normal Temp Range
802.11b: Typ.: 19 +/- 1.5 dBm @
Normal Temp Range
Receive Sensitivity 802.11n HT40/MCS15
270 Mbps: -67 dBm 10% PER
802.11n HT40/MCS0
13.5 Mbps: -75 dBm 10% PER
802.11n HT20/MCS15
130 Mbps: -69 dBm 10% PER
802.11n HT20/MCS0
6.5 Mbps: -79 dBm 10% PER
802.11g 54 Mbps: -74 dBm 10% PER
802.11g 6 Mbps: -84 dBm 10% PER
802.11b 11 Mbps: -86 dBm 10% PER
802.11b 1 Mbps: -92 dBm 10% PER
Antenna Gain in dBi 802.11g: 2.4 GHz <= 1.8 dBi
802.11n: 2.4 GHz <= 1.8 dBi
UPnP able/cert Able
Security Features WEP, WPA, WPA2, RADIUS,
SPI Firewall
Security Key Bits Up to 128-Bit Encryption
Supported File
Systems for
Storage Device FAT16, FAT32, NTFS
Environmental
Dimensions 7.98" x 1.30" x 6.27"
(202.79 x 33.14 x 159.18 mm)
Unit Weight 9.98 oz (283 g)
Power 12V / 1.5A (switching)
Certifications FCC, UL, cUL, IC, RSS210, CE
Operating Temp. 0 to 40°C (32 to 104°F)
Storage Temp. -20 to 60°C (-4 to 140°F)
Operating Humidity 10 to 80%, Relative Humidity,
Noncondensing
Storage Humidity 5 to 90% Noncondensing
Specifications are subject to change without notice.
