Overview
To create your powerline network, you must connect each network device
to a Powerline Adapter. In the first section, you will connect the Powerline
AV Network Adapter (model number: PLE300) to your router. In the next
section, you will connect the Powerline AV 4-Port Network Adapter (model
number: PLS300) to your computers or other network devices.
Internet
Modem
Router
Powerline AV
Network Adapter
Powerline AV 4-Port
Network Adapter
Gaming Console
Computer
Powerline
Diagram of a Typical Powerline Network
Install the First Adapter 1
A. Connect one end of an
Ethernet network cable to the
Ethernet port of the Powerline
AV Network Adapter (model
number: PLE300).
B. Connect the other end of the
cable to the Ethernet port on
your router.
Connect Ethernet Network Cable
Connect Other End of Network Cable
