Linksys SRW2024P Product Data

PRODUCT DATA
BUSINESS SERIES
Features
24 - 10/100/1000 Switched
RJ-45 ports deliver up to 2 Gbps
of throughput per port
2 shared 10/100/1000 miniGBIC
ports
Switching Capacity delivers
wire-speed performance at 48
Gig non-blocking capacity
WebView monitoring allows
administrators to view the
current status and configuration
using their favorite web browser
PoE on 12 10/100 ports supplies
up to IEEE 802.3af maximum of
15.4W per port
Auto MDI/MDIX per port allows
for automatic Cable detection
Port based and 802.1q based
VLANs support up to 256 VLANS
Port Trunking for up to 8 groups
allows you to increase your
bandwidth for each uplink or
Server connection
Port configuration settings for
Link, Speed, Auto MDI/MDIX,
Flow Control, and more
Fully rack-mountable using
the included rack-mounting
hardware
MAC Address table supports up
to 8K MAC Address entries
Optimal platform to support
real-time applications like voice
and video by providing features
like IGMP snooping, multiple
queues (4) with appropriate
scheduling techniques,
prioritization of traffic based on
port, 802.1p, IP TOS/precedence/
DSCP, TCP/UDP port and line
rate forwarding mechanisms
•
•
•
•
•
•
•
•
•
•
•
•
24-Port 10/100/1000 + 2-port shared miniGBIC
Gigabit Switch with WebView
Specications
Model SRW2024P
Ports 24 RJ-45 connectors for 10BASE-T, 100BASE-TX and 1000BASE-T with
2 shared SFP slots
Cabling Type UTP CAT 5 or better for 10BASE-T/100BASE-TX, UTP CAT 5e or better for
1000BASE-T
LEDs Power, Link/Act, Speed
Performance
Switching Capacity 48 Gbps, non-blocking
MAC table size 8K
Number of VLANs 256
Management
Web User Interface Built-in Web UI for easy browser-based conguration (HTTP/HTTPS)
SNMP SNMP version 1, 2c with support for traps
SNMP MIBs RFC1213 MIB-2, RFC2863 Interface MIB, RFC2665 Ether-like MIB, RFC1493
Bridge MIB, RFC2674 Extended Bridge MIB (P-bridge, Q-bridge), RFC2819
RMON MIB (groups 1,2,3,9 only), RFC2737 Entity MIB, RFC 2618 RADIUS
Client MIB
RMON Embedded Remote Monitoring (RMON) software agent supports four
RMON groups (history, statistics, alarms, and events) for enhanced trac
management, monitoring, and analysis.
Firmware Upgrade Web Browser upgrade (HTTP)
TFTP upgrade
Port Mirroring Trac on a port can be mirrored to another port for analysis with a
network analyzer or RMON probe.
Other Management RFC854 Telnet (Menu-driven conguration)
Secure Shell (SSH) and Telnet Management
(SSH)
Telnet Client
SSL security for Web UI
Switch Audit Log
DHCP Client
BootP
SNTP
Xmodem upgrade
Cable Diagnostics
PING
Security features
IEEE 802.1x 802.1x - RADIUS Authentication. MD5 Encryption
Access Control Filtering: MAC-based
SA/DA MAC address
SA/DA IP address
Ethernet Type Field
Protocol
TCP/UDP port numbers
Availability
Link Aggregation Link Aggregation using IEEE 802.3ad LACP
Up to 8 ports in up to 8 trunks
Storm Control Broadcast, Multicast, and Unknown Unicast
Spanning Tree IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree, Fast
Linkover
IGMP Snooping IGMP (v1/v2) snooping provides for fast client joins and leaves of multicast
streams and limits bandwidth-intensive video trac to only the
requestors.

Linksys SRW2024P Specifications

General

Brand	Linksys
Model	SRW2024P
Category	Switch
Language	English
