PRODUCT DATA
BUSINESS SERIES
Features
48 10/100/1000 Switched
RJ-45 ports with auto
MDI/MDI-X cable detection
4 MiniGBIC ports for optical
or copper interconnections
Non-blocking,
store-and-forward switching
mechanism
Simplified QoS management
enabled by advanced
queuing techniques using
802.1p, Diffserv or ToS traffic
prioritzation specifications
Configuration and
monitoring from a standard
web browser with WebView
management
Secure remote management
of the switch via SSH and
SSL secure channel network
protocols
802.1Q based VLANs enable
segmentation of networks
for improved performance
and security
Private VLAN Edge for
simplified network isolation
for guests connections or
autonomous networks
Automatic configuration
of VLANs across multiple
switches through
GVRP/GARP
Automatic port
configuration through auto
MDI/MDIX and 802.1ab
(LLDP)
User/Network port
level security via 802.1X
authentication and
MAC-based filtering
•
•
•
•
•
•
•
•
•
•
•
48-Port 10/100/1000 + 4-Port MiniGBIC
Gigabit Switch with WebView
Specifications
Ports 48 RJ-45 connectors for 10BASE-T, 100BASE-TX and
1000BASE-T with 4 shared SFP slots
Cabling Type UTP CAT 5 or better for 10BASE-T/100BASE-TX,
UTP CAT 5e or better for 1000BASE-T
LEDs Power, Link/Act, Speed
Performance
Switching Capacity 96 Gbps, non-blocking
MAC table size 8K
Number of VLANs 256 VLANs
Management
Web User Interface Built-in Web UI for easy browser-based configuration (HTTP/HTTPS)
SNMP SNMP version v1, v2c, v3 with support for traps
SNMP MIBs RFC1213 MIB-2, RFC2863 Interface MIB, RFC2665 Ether-like MIB,
RFC1493 Bridge MIB, RFC2674 Extended Bridge MIB (P-bridge, Q-bridge),
RFC2819 RMON MIB (groups 1,2,3,9 only), RFC2737 Entity MIB,
RFC 2618 RADIUS Client MIB
RMON Embedded Remote Monitoring (RMON) software agent supports
four RMON groups (history, statistics, alarms, and events) for
enhanced traffic management, monitoring, and analysis
Firmware Upgrade Web Browser upgrade (HTTP)
TFTP upgrade
Port Mirroring Traffic on a port can be mirrored to another port for analysis with a
network analyzer or RMON probe
Other Management RFC854 Telnet (Menu-driven configuration)
Secure Shell (SSH) and Telnet Management
Telnet client
SSL security for Web UI
Switch audit log
DHCP client
BootP
SNTP
Xmodem upgrade
Cable diagnostics
PING
Traceroute
Syslog
Security
IEEE 802.1X 802.1X - RADIUS Authentication. MD5 Encryption
Access Control ACLs - Drop or rate limit based on:
Source and destination MAC-based
Source and destination IP address*
Protocol*
ToS/DSCP*
Port*
VLAN*
Ethertype*
Availability
Link Aggregation Link Aggregation using IEEE 802.3ad LACP
Up to 8 ports in up to 8 trunks
Storm Control Broadcast, Multicast, and Unknown Unicast
Spanning Tree IEEE 802.1d Spanning Tree, IEEE 802.1s Multiple Spanning Tree,
IEEE 802.1w Rapid Spanning Tree, Fast Linkover
IGMP Snooping IGMP (v1/v2) snooping provides for fast client joins and leaves of
multicast streams and limits bandwidth-intensive video traffic to
only the requestors
