PRODUCT DATA
BUSINESS SERIES
Features
8 - 10/100 Switched RJ-45
ports deliver up to 200Mbps
of throughput per port
1.6 Gbps non-blocking,
store-and-forward switching
mechanism
Simplified QoS management
enabled by advanced
queuing techniques using
802.1p, Diffserv or ToS traffic
prioritization specifications
Configuration and
monitoring from a standard
web browser with WebView
management
Secure remote management
of the switch via SSH and
SSL secure channel network
protocols
802.1Q based VLANs enable
segmentation of networks
for improved performance
and security
Automatic configuration
of VLANs across multiple
switches through
GVRP/GARP
Automatic MDI/MDIX
detection support
User/Network port
level security via 802.1X
authentication and
MAC-based filtering
Increased the bandwidth
(up to 8x) and added link
redundancy with Link
Aggregation Control
Protocol (LACP)
•
•
•
•
•
•
•
•
•
•
8-Port 10/100 Switch with WebView
Specifications
Model SRW208
Ports 8 RJ-45 connectors for 10BASE-T and 100BASE-TX
Console port
Auto MDI/MDI-X
Auto-negotiate/Manual setting
Cabling Type UTP CAT 5 or better for 10BASE-T/100BASE-TX
LEDs 10/100 Link/Act, Speed, System
Performance
Switching Capacity 1.6 Gbps, non-blocking
Forwarding Rate 1.19 Mpps wire-speed performance
Layer 2
MAC table size 8K
Number of VLANs 256 active VLANs (4096 range)
VLAN Port-based and 802.1Q Tag-based VLANs
Management VLAN
HOL Blocking Head of line blocking prevention
Management
Web User Interface Built-in Web UI for easy browser-based configuration (HTTP/HTTPS)
SNMP SNMP version 1,2c,3 with support for traps.
SNMP MIBs RFC1213 MIB-2, RFC2863 Interface MIB, RFC2665 Ether-like MIB,
RFC1493 Bridge MIB, RFC2674 Extended Bridge MIB (P-bridge, Q-bridge),
RFC2819 RMON MIB (groups 1,2,3,9 only), RFC2737 Entity MIB,
RFC 2618 RADIUS Client MIB RFC 1215 Traps
RMON Embedded Remote Monitoring (RMON) software agent supports four
RMON groups (history, statistics, alarms, and events) for enhanced traffic
management, monitoring, and analysis.
Firmware Upgrade Web Browser upgrade (HTTP) and TFTP
Port Mirroring Traffic on a port can be mirrored to another port for analysis with a
network analyzer or RMON probe.
Other Management Traceroute
Secure Socket Layer (SSL)
Secure Shell (SSH)
RADIUS
Port mirroring
TFTP upgrade
SSL security for Web UI
DHCP client
BootP
SNTP
Xmodem upgrade
Cable diagnostics
PING
Telnet client (SSH secure support)
Security
IEEE 802.1X 802.1X - RADIUS Authentication. MD5 Encryption
Access Control ACLs - Drop or Rate Limit based on:
Source and Destination MAC-based
Source and Destination IP address
Protocol
TOS/DSCP
Port
VLAN
Ethertype
Availability
Link Aggregation Link Aggregation using IEEE 802.3ad LACP
Up to 8 ports in up to 8 groups
Storm Control Broadcast, Multicast and Unknown Unicast
Spanning Tree IEEE 802.1D Spanning Tree, IEEE 802.1w Rapid Spanning Tree,
IEEE 802.1s Multiple Spanning Tree
IGMP Snooping IGMP (v1/v2) snooping provides for fast client joins and leaves of
multicast streams and limits bandwidth-intensive video traffic to only
the requestors. Support 256 multicast groups.
