ARTIKULAT
Loudspeaker System
Owner’s Manual
English ARTIKULAT 350, 340, 320
CCoonnnneeccttiinngg
We recommend that your ARTIKULAT loudspeakers are unpacked, installed and
adjusted by an authorised Linn retailer.
General
IMPORTANT:
Before making any connections, switch off all products in your system and disconnect
each ARTIKULAT loudspeaker from the mains.
Connection of standard models (ARTIKULAT 350, 340 and 320)
The back panels of the standard models of ARTIKULAT 350, 340 and 320 loudspeakers
are fitted with binding-post terminals for connection of the upper frequency signals (i.e.
upper bass*, mid, tweeter and super-tweeter). These terminals can be used as sockets
for the connection of 4mm banana plugs or can be used as binding posts for the
connection of bare wires or spade-terminated cables.
Important note - (BALANCED AUDIO IN)
Do not connect anything to the BALANCED AUDIO IN (AKTIV bass)
socket - please consult your Authorised Linn Retailer.
In the standard configuration (i.e. the factory setting), the signal
going into the binding post terminals provides the audio to the
AKTIV bass via an internal link. A modification can be carried out by
your Authorised Linn Retailer to allow a direct connection to be
made from your preamplifier to BALANCED AUDIO IN which would
provide improved audio performance.
*ARTIKULAT 350 and 340 only
