Linn Artikulat User Manual

21
ARTIKULAT
Loudspeaker System
Owner’s Manual
Technical Specification English
Technical Specification
ARTIKULAT 350
ARTIKULAT 350
ARTIKULAT 340
ARTIKULAT 340
ARTIKULAT 320
ARTIKULAT 320
Type 6-way floorstander 5-way centre 4-way compact
Mains input 90 - 135V 90 - 135V 90 - 135V
voltage 180 - 265V 180 - 265V 180 - 265V
(auto-sensing)
Mains fuse Schurter FST0034.3217 Schurter FST0034.3217 Schurter FST0034.3217
10 A 250 V 10 A 250 V 10 A 250 V
Power consumption
(fully AKTIV models)
Standby 49 W 42 W 27 W
Rated 100 W 100 W 50 W
Maximum 600 W 600 W 300 W
(continuous)
Power consumption
(standard models)
Standby 30 W 27 W 17 W
Rated 50 W 50 W 50 W
Maximum 300W 300 W 300 W
(continuous)
19 Hz*, 40 Hz, 80 Hz
20 Hz - 33 kHz
19 Hz*, 40 Hz, 80 Hz
30 Hz - 33 kHz
50 Hz*, 80 Hz, 100 Hz
55 Hz - 33 kHz
BASS ROLL-ON
settings
Frequency response -
passive
ARTIKULAT 350
ARTIKULAT 350
ARTIKULAT 340
ARTIKULAT 340
ARTIKULAT 320
ARTIKULAT 320
20 Hz - 33 kHz
All Butterworth at
105 Hz, 392 Hz,
3.8 kHz, 10.9 kHz
4
8
8
6
4
Up to 4-way by
wire or amplifier
Yes
50 Litres
1100 mm (H) x
312 mm (W) x
430 mm (D)
1188 mm (H) x
432 mm (W) x
612 mm (D)
54 kg / 119 lb
64.8 kg / 143 lb
30 Hz - 33 kHz
All Butterworth at
105 Hz, 392 Hz,
3.8 kHz, 10.9 kHz
4
8
8
6
4
Up to 4-way by
wire or amplifier
Yes
40 Litres
290 mm (H) x
840 mm (W) x
400 mm (D)
441 mm (H) x
1004 mm (W) x
625 mm (D)
46.5 kg / 102.5 lb
51.5 kg / 114 lb
55 Hz - 33 kHz
All Butterworth at
392 Hz, 3.8 kHz,
10.9 kHz
4
8
8
6
4
Up to 3-way by
wire or amplifier
Yes
20 Litres
473 mm (H) x
292 mm (W) x
410 mm (D)
658 mm (H) x
394 mm (W) x
584 mm (D)
19.5 kg / 43 lb
23.6 kg / 52 lb
Frequency response -
active
Impedance - active
(upper-bass)
Crossover points
Impedance - active
(super-tweeter)
Impedance - active (mid)
Impedance - active
(tweeter)
Nominal impedance -
passive
Connection options
Magnetic shielding
Operating volume
Shipping dimensions
Shipping weight
Dimensions
Weight
13 mm (0.5") / 25 mm
(1") / 75 mm (3")
domes, 165 mm (6.5")
upper bass,
2 x 200 mm (8")
servo lower bass
87 dB for 1 watt at 1 m
(1 kHz)
Fully AKTIV (internal
modules)
Fully AKTIV (internal
lower bass / external
upper bass and 3-K
Array)
AKTIV lower bass /
passive upper bass
and 3-K Array
0 dB*, -1.5 dB, -3 dB
0 dB*, +2 dB, +4 dB
13 mm (0.5") / 25 mm
(1") / 75 mm (3")
domes, 1 x 200 mm
(8") upper bass, 1 x
200 mm (8") servo
lower bass
87 dB for 1 watt at 1 m
(1 kHz)
Fully AKTIV (internal
modules)
Fully AKTIV (internal
lower bass / external
upper bass and 3-K
Array)
AKTIV lower bass /
passive upper bass
and 3-K Array
0 dB*, -1.5 dB, -3 dB
0 dB*, +2 dB, +4 dB
13 mm (0.5") / 25 mm
(1") / 75 mm (3")
domes, 165 mm (6.5")
87 dB for 1 watt at 1 m
(1 kHz)
Fully AKTIV (internal
modules)
Fully AKTIV (internal
bass / external 3-K
Array)
AKTIV bass / passive
3-K Array
0 dB*, -1.5 dB, -3 dB
0 dB*, +2 dB, +4 dB
Drive units
Efficiency
Crossover
options
TREBLE SHELF
settings (fully
AKTIV models only)
BASS SHELF
settings
* default setting

Linn Artikulat Specifications

General

Brand	Linn
Model	Artikulat
Category	Speaker System
Language	English
