Type 1-way bass reinforcement
Drive unit 300 mm (12") servo bass
Mains input voltage (auto-sensing) 90 - 135V
180 - 265V
Mains supply frequency 50 - 60 Hz
Mains fuse 6.3 A, slow-blow, 5 x 20 mm, Littlefuse 21806.3
Magnetic shielding Yes
External frequency response Adjustable from 10 Hz - 235 Hz in
9 steps. Default is 10 Hz.
Internal frequency response Adjustable from 55 Hz - 130 Hz in 3 steps
and flat (to allow external low pass filtering).
Default is 55 Hz.
Gain Adjustable in 1 dB steps
Line input impedance 18 k
Line output level Electronically in parallel with line input
Power consumption
(fully AKTIV models)
Standby 11 W
Rated 60 W
Maximum (continuous) 150 W
Output power 500 W RMS, 1000 W peak
Operating volume 45 litres
Dimensions 420 mm (H) x 491 mm (W) x 410 mm (D)
Shipping dimensions 596 mm (H) x 595 mm (W) x 534 mm (D)
Weight 27 kg / 59.5 lb
Shipping weight 30 kg / 66 lb
