3.2.3 Midi plus printhead
Figure 17. Midi plus printhead: Ideal Raster Pitch and Raster Rate
68589
MIDI plus PRINTHEAD
Message Type Character matrices
(no. of lines x H x W)
Ideal raster
pitch
(mm)
Maximum
raster rate
(kHz)
Maximum line
speed at ideal
raster pitch
(m/s)
5 Linear Quality 1Lx5x5 0.428 5.33 2.10
7 Linear Quality 1Lx7x5 0.428 4.00 1.61
9 Linear Quality 1Lx9x7 0.428 2.46 1.01
16 Linear Quality
1Lx16x10
2Lx7x5
0.428 0.98 0.41
25 Linear Quality
1Lx25x16
3Lx7x5
0.428 0.68 0.28
34 Linear Quality
1Lx34x24
2Lx16x10
4Lx7x5
0.428 0.37 0.15
