3.2.4 Ultima plus printhead
Figure 18. Ultima plus Printhead: Ideal Raster Pitch and Raster Rate
68590
ULTIMA plus PRINTHEAD
Message Type Character matrices
(no. of lines x H x W)
Ideal raster
pitch
(mm)
Maximum
raster rate
(kHz)
Maximum line
speed at ideal
raster pitch
(m/s)
5 Linear Quality 1Lx5x5 0.428 6.40 2.73
5 Linear Speed 1Lx5x5 0.428 10.66 4.56
5 Linear Wide 1Lx5x5 0.569 12.80 7.28
7 Linear Quality 1Lx7x5 0.428 3.76 1.61
7 Linear Speed 1Lx7x5 0.428 8.00 3.42
7 Linear Wide 1Lx7x5 0.569 9.14 5.20
9 Linear Quality 1Lx9x7 0.428 3.55 1.52
16 Linear Quality 1Lx16x10 0.428 1.28 0.54
16 Linear Speed 1lx16x10 0.428 1.82 0.78
16 Linear Wide 1lx16x10 0.560 1.88 1.05
21 Linear Quality 1Lx21x12 0.428 1.08 0.46
21 Linear Speed 1Lx21x12 0.428 1.36 0.58
25 Linear Quality 1Lx25x16 0.428 0.87 0.37
2x5 Stitched Quality 2Lx5x5 0.428 4.26 1.82
2x5 Stitched Speed 2Lx5x5 0.428 6.40 2.73
2x7 Stitched Quality 2Lx7x5 0.428 3.20 1.36
2x7 Stitched Speed 2Lx7x5 0.428 4.57 1.95
2x7 Stitched Wide 2Lx7x5 0.510 4.57 2.33
3x7 Stitched Quality 3Lx7x5 0.428 1.60 0.68
3x7 Stitched Speed 3Lx7x5 0.428 2.37 1.01
