How To Install and Set Up the 5900 &
7900 Printer
Linx 5900 & 7900
8T 1x 5 Quality 1.82 m/s 1Lx5x5 0.285 6.4 1.82
8T 1x 5 Speed 2.73 m/s 1Lx5x5 0.285 9.6 2.73
8T 1x 5 WIDE 6.83 m/s 1Lx5x5 0.428 16.0 6.84
8T 1x 6 Speed 2.27 m/s 1Lx6x5 0.285 8.0 2.28
8T 1x 7 Quality 1.30 m/s 1Lx7x5 0.285 4.57 1.30
8T 1x 7 Speed 1.95 m/s 1Lx7x5 0.285 6.85 1.95
8T 1x 7 WIDE 5.12 m/s 1Lx7x5 0.428 12.0 5.13
8T 1x 8 Quality 1.13 m/s 1Lx8x5 0.285 4.0 1.14
8T 1x 8 Speed 1.70 m/s 1Lx8x5 0.285 6.0 1.71
8T 1x 9 Quality 1.01 m/s 1Lx9x7 0.285 3.55 1.01
8T 1x 9 Speed 1.51 m/s 1Lx9x7 0.285 5.33 1.52
8T 1x12 Quality 1.13 m/s 1Lx12x8 0.285 4.0 1.14
8T 1x16 Quality 0.85 m/s 1Lx16x10 0.285 3.0 0.85
8T 2x 5 Quality 1.82 m/s 2Lx5x5 0.285 6.4 1.82
8T 2x 6 Quality 1.51 m/s 2Lx6x5 0.285 5.33 1.52
8T 2x 6 WIDE 2.15 m/s 2Lx6x5 0.428 5.05 2.16
8T 2x 7 Quality 1.24 m/s 2Lx7x5 0.285 4.36 1.24
12T 2x 7 WIDE 1.95 m/s 2Lx7x5 0.428 4.57 1.95
12T 2x 7 WIDE 2.27 m/s 2Lx7x5 0.428 5.33 2.28
MINI PRINTHEAD
Message Type Character matrices
(no. of lines x H x W)
Ideal raster
pitch
(mm)
Maximum
raster rate
(kHz)
Maximum
line speed at
ideal raster
pitch
(m/s)
Figure 19. Mini Printhead: Ideal Raster Pitch and Raster Rate (Continued)
