3.2.6 Micro printhead (7900 only)
MK 7 MICRO PRINTHEAD
Message Type Character matrices
(no. of lines x H x W)
Ideal raster
pitch
(mm)
Maximum
raster rate
(kHz)
Maximum line
speed at ideal
raster pitch
(m/s)
4T 1x 5 Quality 1.82m/s 1Lx5x5 0.228 8.00 1.82
4T 1x 5 Wide 4.10m/s 1Lx5x5 0.342 12.00 4.10
4T 1x 7 Quality 1.30m/s 1Lx7x5 0.228 5.71 1.30
4T 1x 7 Wide 2.93m/s 1Lx7x5 0.342 8.57 2.93
4T 1x 7 Wide 5.47m/s 1Lx7x5 0.456 12.00 5.47
4T 1x 7 Wide 8.41m/s 1Lx7x5 0.912 9.23 8.42
4T 1x 8 Quality 1.13m/s 1Lx8x5 0.228 5.00 1.14
4T 1x 8 Wide 2.56m/s 1Lx8x5 0.342 7.50 2.57
4T 1x 8 Wide 3.41m/s 1Lx8x5 0.456 7.50 3.42
4T 1x 8 Wide 6.07m/s 1Lx8x5 0.456 13.33 6.08
4T 1x 9 Quality 1.01m/s 1Lx9x7 0.228 4.44 1.01
4T 1x 9 Wide 2.27m/s 1Lx9x7 0.342 6.67 2.28
4T 1x 9 Wide 3.03m/s 1Lx9x7 0.456 6.67 3.04
4T 1x 9 Wide 5.47m/s 1Lx9x7 0.456 12.00 5.47
4T 1x12 Quality 0.59m/s 1Lx12x8 0.228 2.61 0.59
4T 1x12 Speed 0.68m/s 1Lx12x8 0.228 3.00 0.68
4T 1x16 Quality 0.50m/s 1Lx15x10 0.228 2.22 0.51
4T 1x24 Quality 0.29m/s 1Lx23x16 0.228 1.28 0.29
4T 1x24 Quality 0.29m/s 1Lx25x16 0.228 1.28 0.29
4T 1x32 Quality 0.19m/s 1Lx32x24 0.228 0.85 0.19
4T 2x 5 Quality 0.91m/s 2Lx5x5 0.228 4.00 0.91
4T 2x 5 Wide 1.36m/s 2Lx5x5 0.342 4.00 1.37
4T 2x 5 Wide 2.05m/s 2Lx5x5 0.342 6.00 2.05
4T 2x 5 Wide 2.73m/s 2Lx5x5 0.456 6.00 2.74
4T 2x 7 Speed 0.65m/s 2Lx7x5 0.228 2.86 0.65
4T 2x 7 Speed 0.97m/s 2Lx7x5 0.228 4.29 0.98
4T 2x 7 Wide 0.97m/s 2Lx7x5 0.342 2.86 0.98
4T 2x 7 Wide 1.46m/s 2Lx7x5 0.342 4.29 1.47
4T 2x 7 Wide 1.95m/s 2Lx7x5 0.456 4.29 1.95
Figure 20. Micro Printhead: Ideal Raster Pitch and Raster Rate
