Congratulations!
C
ongratulations on your purchase of the Lionel Big Boy locomotive and tender! On the
outside, this locomotive features numerous prototypical details and expert decoration
in your favorite livery. Inside the body, this locomotive is equipped with some of the most
advanced sounds and controls in model railroading. This powerful locomotive is ready for
duty on your layout.
Features of this locomotive
• LEGACY Control System equipped—able to run in the TrainMaster
Command Control mode, in the conventional environment with only a
standard transformer, or with the new LEGACY Control System
• Odyssey II speed control with ON/OFF switch
• Refined Conventional Transformer Control Mode with lower starting
speeds, improved smoke output
• LEGACY RailSounds sound system with quilling whistle
• FatBoy speaker for the ultimate in sound reproduction
• High-torque Pittman
®
motor with momentum flywheel
• Wireless Tether connection between locomotive and tender
• Illuminated headlight and backup lights on locomotive
• Illuminated marker lights on tender
• Illuminated classification lights on locomotive
• ElectroCoupler on rear of tender
• Variable ashpan glow
• Flickering firebox in cab
• Puffing synchronized fan-driven smoke unit with adjustable smoke output
• Minimum curve: O-72
