Rev: 12.15.21 Page 4 CCD-0005300
Installation
Installing the Power Steps
A
A
A
A
Fig. 1
1. If necessary, the use of a 12V power source to extend the steps may be used to improve accessibility of
the mounting holes in the top plate of the step.
2. Place steps under the pre-drilled holes in the chassis (Fig. 1A).
Stand to the side of the step during this operation to avoid the moving parts.
B
D
C
To Next Page
