Lippert Tire Linc Installation And Owner's Manual

14
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc
®
AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Configure All Sensors
As an option to configuring sensors individually, all the
sensors can be configured simultaneously�
1. Press the arrow by Congure All Sensors (Fig.27A)�
2. The next screen will feature settings for all
programmable limits (Fig.28)� Select the arrow to the right
of the setting to establish pressure and temperature
thresholds for all the sensors�
Fig.27 Fig.28
A

Lippert Tire Linc Specifications

General

Type	Tire Pressure Monitoring System (TPMS)
Compatibility	RV and Trailer tires
Battery Life	Up to 5 years
Operating Temperature Range	-40°F to 185°F (-40°C to 85°C)
Connectivity	Bluetooth
Accuracy	±1 psi
Wireless Range	Up to 100 feet
Mobile App	Yes (Android and iOS)
Display	Mobile App
Power Source	CR1632 battery
