10. INFORMATION ON DEFECTS AND MALFUNCTIONS
DEFECTS
CAUSE
SOLUTION
Mower does not cut grass.
Worn knives. Loose V-belts.
Replace knives. Tighten V-belts.
Mower gets hot and starts
operating loudly.
No oil in gear box.
Refill oil.
Mower vibrates excessively.
No holder or knife.
Install holder or knife.
Mower operates despite power
input connection is off.
Worn overrunning clutch.
Replace large pulley.
Excessive inter-tooth clearance.
Worn gear wheels.
Adjust using spacers.
Mower loses knives.
Worn knife holders.
Replace holders.
11. SPECIFICATION
Operational data for mower Z-178, Z-178/1, Z-178/2 and Z-178/3 is given in Table 2.
Table 2. Operational data
No.
Technical parameters
Unit of measure
Mower data
1.
Model according to KTM
-
Z-178
Z-178/1
Z-178/2
Z-178/3
2.
Mower type
Rear rotary
3.
Working width
m
1.65
1.35
1.85
2.10
4.
Power demand
kW
up to 22
up to 18
up to 35
up to 56
5.
Number of working drums
pcs
2
6.
Working disc dimension
m
0.78
0.63
0.90
1.01
7.
Number of knives
pcs
6
4
6
12
8.
Mowing height
mm
32/40/44
(1)
9.
Drum rotating speed
rpm
2050
2350
1900
1600
10.
Rotational speed, PTO
rpm
540
11.
Mower dimensions (working/transport position):
• length
m
1.69/3.28
1.58/2.86
2.00/3.40
3.60
2.00/2.35
• width
m
3.32/1.91
2.85/1.58
3.60/2.00
4.10/1.80
• height
m
1.22/1.56
1.26/1.55
1.25/1.60
1.25/2.40
12.
Working speed
km/h
up to 12
13.
Working capacity
ha/h
up to 1.4
up to 1.0
up to 1.8
up to 2.4
14.
Number of operators
-
1
15.
Transport speed
km/h
up to 15
16.
Transport clearance
m
0.25 - 0.40
17.
Energy source:
• tractor class
0.9 9
0.6 6
0.9 9
• towed weight
kN
9
6
9
14
18.
U-joint shaft:
1 (6-spline shaft ends)
540 rpm)
With one-way
clutch!!!
• type: (acc. to tractor PTO)
-
• symbol
7103056CE007007 (acc. to Bondioli & Pavesi)
7143-066-CE-
007-096
• capacity (series)
100
• nominal torque
Nm
390
540
• nominal transferred power
kW
22
• nominal length of shaft (retracted)
(2)
mm
560
• shaft marking
“
use shaft marked with safety “B” mark
19.
Machine weight
kg
365
310
470
690
1) manufacturer assembles mower for mowing height of about 32 mm
2) measured between axes of cross-pieces
