LISICKI Z-178/1 User Manual

27
Z-178
1,65 m
Z-178/2
1,85 m
Z-178/1
1,35 m
Z-178/3
2,10 m
5-178-010-378 2 - - -
5-178-010-378/2 - 2 - -
5-178-010-193 - - 2 -
5-178-010-378/3 - - - 2
25 Cover 5-176-010-439 2 2 2
26 Knife 5-178-010-454 12 12 8 24
Shim Ø45 x Ø55 x 0,1 5-178-010-467
Shim Ø45 x Ø55 x 0,3 5-178-010-470
Shim Ø45 x Ø55 x 0,5 5-178-010-482
Shim Ø45 x Ø55 x 1,0 5-178-010-495
28 Lock bolt M12x25 10.9 5-178-010-502 12 12 - 24
29 Countersunk head bolt M12x25 5-178-010-515 12 12 12 12
5-178-010-528 2 - - -
5-178-010-528/2 - 2 - -
5-178-010-200 - - 2 -
5-178-010-528/3 - - - 2
32 Sealing ring round Ø70 x Ø4 5-178-010-543 2 2 2 2
34 Spring retaining ring Z25 PN-81/M-85111 4 4 4 4
35 Parallel key A8x7x80 5-178-010-584 2 2 2 2
36a Ball bearing 6210-Z-C3 PN-85/M-86100 2 2 2 2
36b Ball bearing 6209-Z-C3 PN-85/M-86100 2 2 2 2
37 Ball bearing 6210-2Z-C3 PN-85/M-86100 2 2 2 2
38 Ball bearing 6305-ZZ lub 2RS PN-85/M-86100 2 2 2 2
39 Spring retaining ring Z45 PN-81/M-85111 2 2 2 2
40 Sealing ring B40x62x10 PN-72/M-86965 2 2 2 2
41 Felt seal 5x8x12 PN-77/M-86012 2 2 2 2
5-178-010-812 2 2 2 -
5-178-010-812/3 - - - 2
Bolt M10x30-8.8-B-Fe/Zn8c PN-85/M-82105 16 16 - 20
Bolt M10x35-8.8-B-Fe/Zn8c PN-85/M-82105 - - 16 -
44 Nut M12-8-B-Fe/Zn8c PN-86/M-82144 12 12 - 24
45 Spring washer 10,2Fe/Zn9 PN-77/M-82008 28 28 28 32
46 Spring washer 12,2Fe/Zn9 PN-77/M-82008 12 12 - 12
Bolt M10x20-8.8-B-Zn PN-85/M-82105 12 12 12 12
Bolt M10x30-8.8-B-Zn PN-85/M-82105 12 12 12 12 Use together with dist. ring pos. 5
as needed
30
Sliding disc complete
21
42
Pressure ring
Working disc
47
27
43
Remarks
Item no.
in Fig.
Part name
Part number or standard
Quantity
