Z-178/2

1,85 m

Z-178/3

2,10 m

5-178-020-841 1 -

5-178-020-841/3 - 1

5-178-020-842 1 -

5-178-020-842/3 - 1

3 Welded head 5-178-020-083/3 1 1

4 Flap, set 5-178-020-843 1 1

5 Flap cord 5-178-020-844 1 1

Pin Ø25h9x55 5-178-020-825 1 1

Pin Ø14h9x60 5-178-020-828 1 1

Pin Ø22h9x55 5-178-020-826 2 2

9 Flap spring 5-178-020-526 1 1

10 Hydraulic hose, set 5-178-020-850 1 1

11 Straight connection M18x1,5 - G3/8" PN-EN ISO 8434-1 1 1

12 Hydraulic plug cover 5-178-020-851 1 1

13 Hydraulic quickcoupling, plug EURO M18x1,5 ISO 7241-A 1 1

14 Hydraulic cylinder, set 5-178-020-852 1 1

Split pin S-Zn Ø6x40 PN-76/M-82001 4 4

16 Washer 25,5 PN-63/M-82004 1 1

17 Bolt M14x1,5x100 5-178-020-827 1 1

18 Bolt M12x35-8.8-B-Fe/Zn8C PN-85/M-82101 1 1

19 Self-locking nut M14x1,5-8-B-Fe/Zn8c PN-86/M-82175 1 1

20 Nut M12-8-B-Fe/Zn8C PN-86/M-82144 1 1

21 2x widened washer M12 PN-M-82019 1 1

23 Washer 14,5 PN-63/M-82004 1 1

24 Washer 22,5 PN-63/M-82004 2 2

25 Bottom shackle 5-178-020-845 1 1

Quantity

Remarks

Shackle

Welded shackle, set

Item no.

in Fig.

Part name

Part number or standard

Table 6. Hydraulic lifting system.

LISICKI Z-178/1 User Manual
