LISICKI Z-178 - Page 25

22
Z-178
1,65 m
Z-178/2
1,85 m
Z-178/1
1,35 m
Z-178/3
2,10 m
5-041-010-248 1 - - -
5-041-010-248/2 - 1 - -
5-041-010-076 - - 1 -
5-041-010-248/3 - - - 1
Shim Ø25 x Ø35 x 0,1 5-178-010-098
Shim Ø25 x Ø35 x 0,3 5-178-010-105
Shim Ø25 x Ø35 x 0,5 5-178-010-118
Shim Ø25 x Ø35 x 1,0 5-178-010-120
5-178-010-187 1 - 1 -
5-178-010-187/2 - 1 - 1
5-178-010-190 1 - 1 -
5-178-010-190/2 - 1 - 1
5-178-010-658 1 - - -
5-178-010-658/2 - 1 - -
5-178-010-048 - - 1 -
5-178-010-658/3 1
5-178-010-645 1 - - -
5-178-010-645/2 - 1 - -
5-178-010-063 - - 1 -
5-178-010-645/3 1
5-178-010-235 1 - - -
5-178-010-235/2 - 1 - -
5-178-010-124 - - 1 -
5-178-010-235/3 1
5-178-010-250 1 - - -
5-178-010-250/2 - 1 - -
5-178-010-089 - - 1 -
5-178-010-250/3 1
5-178-010-263 1 - - -
5-178-010-263/2 - 1 - -
5-178-010-263/1 - - 1 -
5-178-010-263/3 1
9
Drive shaft
Pulley, small
Shackle, set
Welded main frame
Inner drive shaft, set (poz. 8, 9, 10, 11, 12, 21,
22, 24, 26, 28)
4
6
7
8
Welded cover
Left bearing housing
2
3
Right bearing housing
Remarks
Item no.
in Fig.
Part name
Part number or standard
1
Quantity
as needed
Table 1. Main frame body and cutting unit drive.
