LISICKI Z-178 - Page 26

23
Z-178
1,65 m
Z-178/2
1,85 m
Z-178/1
1,35 m
Z-178/3
2,10 m
5-178-010-276 1 - 1 -
5-178-010-276/2 - 1 - 1
5-178-010-289 1 - 1 -
5-178-010-091 - 1 - 1
12 Support sleeve 5-178-010-291 2 2 2 2
13 Sealing sleeve 5-178-010-337 8 4 8 4
5-178-010-352 1 - - -
5-178-010-352/2 - 1 - -
5-178-010-213 - - 1 -
5-178-010-352/3 - - - 1
5-178-010-673 2 - 2 -
5-178-010-673/2 - 2 - -
5-178-010-673/3 - - - 2
5-178-010-660 1 - 1 -
5-178-010-660/2 - 1 - -
5-178-010-660/3 - - - 1
5-178-010-673/K 1 - - -
5-178-010-673/2 - 1 - -
5-178-010-673/1 - - 1 -
5-178-010-673/3 - - - 1
18 Plug 5-178-010-441 1 1 1 1
20 Parallel key A8x7x36 5-178-010-597 1 1 1 1
Parallel key A8x7x50 5-178-010-604 3 3 3 2
Parallel key A8x7x70 5-178-010-604/3 - - - 1
Parallel key A8x7x36 5-178-010-597 1 - - -
Parallel key A8x7x50 5-178-010-604 - 1 1 1
Ball bearing 6305 PN-85/M-86100 2 - 2 -
Ball bearing 6206 PN-85/M-86100 - 3 - 3
Ball bearing 6305-2Z-C3 PN-85/M-86100 2 - 2 -
Ball bearing 6206-2Z-C3 PN-85/M-86100 - 3 - 3
Spring retaining ring Z25 PN-81/M-85111 2 - 2 -
Spring retaining ring Z30 PN-81/M-85111 - 2 - 2
21
23
24
14
15
16
17
Drive gear
Gear wheel, small
Gear wheel, big
Inner drive shaft
Hub
Back plate
11
10
22
26
Remarks
Item no.
in Fig.
Part name
Part number or standard
Quantity
Table 1. continued.
