LISICKI Z-178 - Page 27

24
Z-178
1,65 m
Z-178/2
1,85 m
Z-178/1
1,35 m
Z-178/3
2,10 m
27 Spring retaining ring W62 PN-81/M-85111 1 2 1 2
Sealing ring A25x52x10 PN-72/M-86964 1 - 1 -
Sealing ring A30x52x10 PN-72/M-86964 - 1 - 1
29 Bolt M10x60-8.8-B PN-85/M-82101 4 8 4 8
30 Bolt M10x20-8.8-B-Fe/Zn8c PN-85/M-82105 14 16 10 18
31 Bolt M10x25-8.8-B-Fe/Zn8c PN-85/M-82105 8 8 8 8
Spring washer 12,2Fe/Zn9 PN-77/M-82008 1 - 1 -
Spring washer 14,2Fe/Zn9 PN-77/M-82008 - 1 - 1
33 Bolt M10x35-8.8-B-Fe/Zn8c PN-85/M-82105 12 12 12 12
34 Spring washer 12,2Fe/Zn9 PN-77/M-82008 5 5 5 5
Bolt M12x30-8.8-B-Fe/Zn8c PN-85/M-82105 1 - 1 -
Bolt M14x30-8.8-B-Fe/Zn8c PN-85/M-82105 - 1 - 1
37 Nut M10-8-B-Fe/Zn8c PN-86/M-82144 26 28 22 30
38 Nut M12-8-B-Fe/Zn8c PN-86/M-82144 1 1 1 1
39
Retaining pin Ø6x16 PN 85021 4 4 4 4
40 Washer 10,4-Fe/Zn9 PN-77/M-82008 22 24 18 26
41 Spring washer 10,2Fe/Zn9 PN-78/M-82005 12 12 12 12
42 Two-hole bent washer 5-178-010-632 2 4 2 4
36
32
28
Remarks
Item no.
in Fig.
Part name
Part number or standard
Quantity
Table 1. continued.
