LISICKI Z-178 - Page 32

29
Z-178
1,65 m
Z-178/2
1,85 m
Z-178/1
1,35 m
Z-178/1
(60)
1,35 m
Z-178/1
(80)
1,35 m
Z-178/3
2,10 m
5-178-020-160 1 - - - - -
5-178-020-160/2 - 1 - - - -
5-178-020-189 - - 1 1 1 -
5-178-020-160/3 - - - - - 1
5-178-020-287 1 - 1 1 1 -
5-178-020-287/2 - 1 - - - -
5-178-020-287/3 - - - - - 1
5-178-020-720 1 - - - - -
5-178-020-720/2 - 1 - - - -
5-178-020-720/1 - - 1 1 1 -
5-178-020-720/3 - - - - - 1
5-178-020-144 1 - - - - -
5-178-020-144/2 - 1 - - - -
5-178-020-280 - - 1 - - -
5-178-020-280/60 - - - 1 - -
5-178-020-280/80 - - - - 1 -
5-178-020-144/3 - - - - - 1
5-178-020-157 1 - - - - -
5-178-020-157/2 - 1 - - - -
5-178-020-293 - - 1 - - -
5-178-020-293/60 - - - 1 - -
5-178-020-293/80 - - - - 1 -
5-178-020-157/3 - - - - - 1
5-178-020-172 1 - 1 1 1 -
5-178-020-172/2 - 1 - - - -
5-178-020-185 1 - - - - -
5-178-020-185/2 - 1 - - - -
5-178-020-191 - - 1 1 1 -
5-178-020-185/3 - - - - - 1
5 Key carrier pin 5-178-020-198 1 1 1 1 1 -
6 Sleeve 5-178-020-205 1 1 1 1 1 -
7 Coupling spring 5-178-020-218 1 1 1 1 1 -
Key carrier
Front cover, guard set
Rear cover, guard set
Pulley
Safety device, set (poz. 10, 11, 12, 13, 14, 15,
46)
Part number or standard
Remarks
Quantity
3
1
2
4
Wheel with coupling (poz. 3, 4, 5, 6, 7, 31,
36, 37)
Driving head (poz. 27, 28, 29, 30, 32, 33, 35,
40, 42, 43, 54)
Item no.
in Fig.
Part name
Table 3. Drive train and central beam
