LISICKI Z-178 - Page 42

39
Z-178/2
1,85 m
Z-178/3
2,10 m
5-178-020-841 1 -
5-178-020-841/3 - 1
5-178-020-842 1 -
5-178-020-842/3 - 1
3 Welded head 5-178-020-083/3 1 1
4 Flap, set 5-178-020-843 1 1
5 Flap cord 5-178-020-844 1 1
6
Pin Ø25h9x55 5-178-020-825 1 1
7
Pin Ø14h9x60 5-178-020-828 1 1
8
Pin Ø22h9x55 5-178-020-826 2 2
9 Flap spring 5-178-020-526 1 1
10 Hydraulic hose, set 5-178-020-850 1 1
11 Straight connection M18x1,5 - G3/8" PN-EN ISO 8434-1 1 1
12 Hydraulic plug cover 5-178-020-851 1 1
13 Hydraulic quickcoupling, plug EURO M18x1,5 ISO 7241-A 1 1
14 Hydraulic cylinder, set 5-178-020-852 1 1
15
Split pin S-Zn Ø6x40 PN-76/M-82001 4 4
16 Washer 25,5 PN-63/M-82004 1 1
17 Bolt M14x1,5x100 5-178-020-827 1 1
18 Bolt M12x35-8.8-B-Fe/Zn8C PN-85/M-82101 1 1
19 Self-locking nut M14x1,5-8-B-Fe/Zn8c PN-86/M-82175 1 1
20 Nut M12-8-B-Fe/Zn8C PN-86/M-82144 1 1
21 2x widened washer M12 PN-M-82019 1 1
23 Washer 14,5 PN-63/M-82004 1 1
24 Washer 22,5 PN-63/M-82004 2 2
25 Bottom shackle 5-178-020-845 1 1
Quantity
Remarks
Shackle
2
1
Welded shackle, set
Item no.
in Fig.
Part name
Part number or standard
Table 6. Hydraulic lifting system.
