Designing a System
6D
Since the radiator comes with most radiator mounting options, there are only two additional choices.
Radiator Mounting Options
The LA-342 dual radiator mounting bracket allows you to mount two radiators together
(vertically or horizontally). This includes short lengths of coaxial RF and CAT-5 power cables.
Dual radiator mounting
1
The LA-337 is a oor stand for portable applications.
Floor stand
2
6E
Fill in the number and type of LA-205 power supplies required (if any).
Radiator Power Supplies
6E
From the System Layout Worksheet, insert the cable lengths for the preassembled coaxial RF cables (LA-391) and
CAT-5 power cables (LA-393).
Cables
6F
For US customers, Listen Technologies oers the ADA Compliance Signage Kit (LA-304). This aids in
complying with US ADA regulations.
Other Accessories
