Turn off circuit breakers and wall switch to the fan
supply line leads.
DANGER: Failure to disconnect power supply
prior to installation may result in serious injury or
death.
1.
Check to make sure outermost edge of small fans
will be at least 30 in. from any obstruction. Check
downrod (A) length to ensure blades will be at least
10 ft. above the floor when smaller fans are in fully
tilted position.
3.
6
ON
OFF
ON
OFF
3
1
This fan can only be mounted with the downrod in
the motor assembly (D).
NOTE: Angle mount or closemount configurations
are not available for this fan.
2.
2
10 ft
min.
30 in.
min.
INITIAL INSTALLATION
D
A
