LIYU DMS FH3204 - List of Main Technical Specifications; Basic Specification

Maschinenvertrieb
LIYU DMS GmbH
www.liyu-dms.com 4 info@liyu-dms.com
List of main technical specifications:
 Basic specification
Machine Model FH3204 / FH3206 / FH3208
Print Technology Piezo continuous drop-on demand (DOD)
Print Head KM1024iMAE-C
Print Head Control By adjusting the voltage by software
Print Head
Configuration
Details please refer to configuration instructions.
Maximum Breadth 3230
Maximum
Resolution
720 x 1440 dpi
Ink Type Scattered direct-injection ink
Color Profile K C M Y LC LM
Drying Device Self-innovated 0.6 KW infrared dryer
Ink Supply System Automatic continuous ink supply with vacuum negative pressure
Media Adsorption Optional table vacuum adsorption
Table
Pressure-bearing
15 kg/m
2
Package Size 5220L x 1100W x 2150H mm
Machine
Dimensions
5555L x 900W x 1800H mm
Machine
Gross
Weight
2700 kg
Printing Interface PCIE
Power Interface 220V±10% 50HZ
