Control Functions
Technical Specifications
Electricals
Generator system 12 Volt 96 Watt.
Head lamp 12 Volt 35/35 Watt
Tail light bulb 12 Volt 5 Watt
Stop light bulb 12 Volt 10 Watt
Speedolight bulb 12 Volt 1.2 Watt x 2
Turn signal light bulb 12 Volt 10 Watt
Tell tale lamp 12 Volt 1.2 Watt x 4
Horn 12 Volt DC Horn fitted with AC to DC convertor
Battery 12 Volt 9 Ah (for auto start model)
Fuse 8 Amp (for auto start model)
Maximum speed 90 kms/hr
CONTROL FUNCTIONS
1. LOCKING SYSTEM
The LML
has a single key for
locking the steering column, glove
compartment, utility box and seat, as
well as for the ignition.
1.1 Steering lock-cum ignition switch.
Locking the Handlebar : First turn the
handlebar to the extreme left and then
turn the key anti-clockwise to lock
position. Pull out the key after locking
(Fig.14).
Un-locking the Handlebar : Insert the
key in ignition switch and turn it clock-
wise to unlock the handlebar. To switch
on the ignition turn the key further clock-
wise to "ON" position (Fig. 15).
