INITIAL EXAMINATION AND INSTALLATION
2.1 COMMISSIONING
(i) Remove all packing materials.
(ii) Check for signs of external damage (this MUST be reported
immediately to the Carrier and Supplier).
(iii) Check that the electrical supply details on the information Rating Plate,
which is fitted to the rear panel, are in accordance with the available
electrical supply.
(iv) All cooled incubators are supplied with a 3 pin moulded plug, which if
not suitable may be replaced by an electrician or other competent
person. Connect conductors as follows: BROWN to live, BLUE to
neutral, GREEN/YELLOW to earth.
(v) Position the cooled incubator so that approximately 100mm of free
space exists around the cooled incubator.
(vi) Adjust levelling foot or feet (depending on model) so that the cooled
incubator sits firmly. Lockable castors (where fitted) MUST be locked.
(vii) Please ensure that the refrigeration switch, which is fitted on the rear
panel on the right hand side, is in the ON position (down).
(viii) After the cooled incubator has been sited allow 24 hours before
switching on.
2.2. CONTROLS – Common to All Models
2.2.1 Fuse
A 1.25" TYPE F cartridge fuse in a screw fitting carrier is located at
the rear of the control compartment adjacent to the Serial Number plate
on which the fuse value is indicated.
2.2.2. Refrigeration Switch
To the rear of the control compartment on the right hand side is the
refrigeration isolator switch. This switch should always be in the ON
position (down) except (A) when the cooled incubator is to be used at
prolonged periods set at an operating temperature of 10ºC or more
above ambient, or (B) when defrosting the cooled incubator.
2.2.3 Non-Adjustable Overheat Protection Device
