14
Step 6
continued
NOTE:
When properly installed, the Lockly logo blinks red when door
opens and closes.
DOOR FRAME SENSOR (Q)
Manually retract deadbolt and close door. Dry fit sensor Q to door
frame and check for alignment. If needed, raise the height of the
sensor to be more level with sensor P by adding 1 or 2 of the included
adhesive foam pads. Once satisfied both sensors are as level as
possible, remove film from adhesive and install with arrows aligned
to each other with less than a 3/4" gap between each sensor.
INSTALLING WIRED DOOR SENSOR
Q
To Next Page
