13
LOCK SENSOR (P)
Install on the interior side only. If necessary, trim tab from sensor P
for doors with 2-3/8" (60mm) backset. Clean surface of door and
doorframe, remove film from adhesive, attach and secure close to
door edge as shown.
INSTALLING WIRED DOOR SENSOR
Step 6
Make sure you have prepared the door sensors for installation,
see step 3.
2-3/4" (
70mm)
2-3/8" (
60mm)
P
To Next Page
