10
INSTALLING THE LOCK (EXTERIOR)
Step 4
Exterior
Install the exterior lock as shown
to the left by aligning the lock
straight and passing the cable and
attached rods through the lockset.
Align the lock straight and press
hard (if you use the Adhesive tape
in step 3.4) to secure the top of the
lock.
Pass the Spindle C through
the center of the lockset, and
the round rods through the sides
in their respective holes. The cable
should run underneath the lockset.
1
2
3
