NOTE: If you need to disconnect
the cable, make sure to press
the snap tab to release the plug
before carefully pulling it out.
Do not force, as this may result
in damaging the lock.
Plug the cable coming through mounting plate (D) into the interior assembly (F) as shown.
Tuck cable under eyelet hooks and route to the right on interior assembly (F).
INSTALLING THE INTERIOR ASSEMBLY (F)
11
Step 5
Plug into , match red side
of plug with red on socket - insert
tightly.
X
X
Y
Y
To Next Page
