3
Prepare door: remove existing deadbolt or use provided template to bore new holes.
Preparation
1- ⅜" (35mm) to 2" (50mm)
1" (25mm)
*Optional
* Use goggles to protect eyes if you need to drill door holes.
2-⅜" (60mm)
or
2-¾" (70mm)
Cross-bore 2-⅛" (54mm)
REPLACE YOUR EXISTING OLD DEADBOLT. USE THE INCLUDED DEADBOLT DESIGNED AND
OPTIMIZED FOR LOCKLY SMART LOCKS. The included deadbolt integrates a smart door
sensor to detect the open / closed status of your door. Depending on the gap between
door and door frame, you may need to increase the depth of the groove.
