Note: Prior to installation the door must be clear of any obstructions. See page 9 for door prep.
5
Surface Mount Metal Door Installation Steps
Surface Mount Metal Door Installation Parts
A
1-Front Unit
C
2-Locking Nuts
B
1-Rear Unit
Required Tools
3/8” Socket
(deep socket required)
Place the mounting screw posts of the front unit (A)
through the lock mounting holes on the front of the
door.
Step 1
While holding the front unit (A) against the front of the
door, place the rear unit (B) against the rear face of the
door. Align the mounting holes with the mounting screw
posts from the front unit (A).
Step 2
To Next Page
