Loewe 66437 - Baugruppenübersicht; Components Chart

39
L2700
Art.-Nr. Art. No. 66441. B/L/V/S/K 49 66437. B/L 48 664439. B/L 48
Geräte-Typ
TV set type Individual 32 SEL HD DR+ DVB-T/C CI Individual COMP 40 HD DR+ DVB-T/C/S CI Individual COMP 46 HD DR+ DVB-T/C/S CI
Baugruppen • Components
Signal Board
89444
351 X
550 X X
Basic Board
89666
361 X
371 X
381 X
389 X
Buchsenplatte
Connector Board
89194 050 X X X
Bedienteil+IR
Control Unit+IR
89966 050 X
Bedienteil+IR
Control Unit+IR
89835 050 X X
LCD Panel Kit 32“
Samsung L16
89951 001 X
LCD Panel Kit 40“
Samsung L01
89930 001 X
LCD Panel Kit 46“
Samsung L01
89834 001 X
Tuner
89222 071/074
SAT S2
89565 050 X X
AC3 89781 050 X X
DR+/MPEG
enthält/contains
89612.050
89832 080 X X X
DF/CRESTRON 89634 050 X X X
CI Twin
89905 050 X
Fernbedienung Assist
Remote Control Assist
89900 A00 X X X
ARS • Retrofit Kit
SAT S2 Twin
enthält/contains
89565.050
89565 080 X
AC3
enthält/contains
89781.050
89781 080 X
Service Hilfsmittel
Service Tools
Service Tablestand Compose 90437 960 X X
Baugruppenübersicht • Components chart
