Loewe klang 5 - Connection;Set-Up Solution with Two Subwoofers Via DIGITAL AUDIO LINK and LOEWE KLANG LINK (5.2 System)

Loewe klang 5 subwoofer
Operating manual
9
english

Configuration examples
Connection/set-up solution with two subwoofers via DIGITAL AUDIO
LINK and LOEWE KLANG LINK (5.2 system)
If you use a 5.2 system with a Loewe klang link box, you can connect the speakers
and subwoofers much more easily and without much effort. This applies also to
other connection/set-up solutions using the Loewe klang link box.
How to connect the subwoofer via DIGITAL AUDIO LINK is described on page
10.
klang 5 subwoofer
(1)
klang 5 subwoofer
(2)
Loewe klang link
DIGITAL AUDIO LINK
TV set
Surround
left
Front
left
Front
right
Surround
right
TV speaker
as centre speaker
klang 5 subwoofer (1)
klang 5 subwoofer (2)
Front
left
Front
right
Surround
left
Surround
right
TV speaker
as centre speaker
An example of a 5.2 system
A set-up example of a 5.2 system
