33
Diagram:
Connection of the L 2 A as front and stereo speaker as well as Surround Sound speaker
to a Dolby Digital Decoder and a hi-fi system.
L 2 A
L 2 A
Legro
LS 81 SW
L 2 A L 2 A
LOEWE
Cinch cable
Subwoofer
Cinch cable
not required
for radio connection
Speaker cable
for passive connection
Front speaker
Connection: L 2 A via cinch cable.
Retrospective radio fitting
is possible from early in 2000
LOEWE
Rear speaker
+ –
