463-0620-01 Rev A. June-201516
Setting US Metric
Max Speed 40 MPH 60 km/h
Speed Units MPH km/h
Distance Units Miles km
Pressure Units PSI kPa
Volume Units Gal L
Temperature Units ºF ºC
620 Operation and Troubleshooting Guide
plus
CAN
®
System Menu
Configure system function
Demo
Select demo mode
Demo Mode generates simulated gauge data to
demonstrate display operation. Mode 3 also generates
fault messages.
Mode 0 – disabled (default)
1 – simulate engine and speed
2 – simulate engine
3 – Mode 1 with active faults
Note: Demo Mode is automatically disabled
when J1939 data is received.
Restore Defaults
Restore US or metric defaults
Common Settings
Language English
Button Beep On
Service Timers Off
Display Mode Analog Gauges, default set
Quad Adjust Off
Demo Mode 0 (disabled)
Engine Source 0 (Engine 1)
Display Address 40
Alarm Filter Glb (global)
SPN Version 1
Speed Source Auto
PIN Entry Off
PIN 1111
Max RPM 2500
Voltmeter 12V (16 V range)
