BATTERY INSTALLATION
You will need four 1.5V AA (LR6) batteries.
➤
Open the battery box lid by loosening the large screw underneath
the battery box with a screwdriver or coin and then lifting the lid.
➤
Put the batteries in, starting with the two centre ones. It is best
to put the flat end (-ve) of each battery in first, which depresses
the spring in the battery compartment.
➤
Insert the two lugs into the holes and close the lid.
➤
Do up the screw again. Do not tighten too much!
LIFT LID TO
ADD BATTERIES
SCREW
(underneath)
JOIN OTHER
LOGIBLOCS HERE
25
FUSE REPLACEMENT
As an added safety feature there is a 1A fuse contained in the BATTERY
BOX. If in the unlikely event this gets broken you will need to obtain a
replacement BATTERY BOX. Please send the old one back to us, enclosing
your own address and tell us what you think caused the fuse to blow.
